Bmi Usa 20375 Black Xh Malleable Iron 90 Degree Street Elbow

Product Description

The BMI USA 20375 is a 3/4-inch extra heavy (XH) malleable iron 90-degree street elbow finished in black. Street elbows feature one male and one female threaded end, allowing a direct connection without a separate nipple. The extra heavy wall rating makes this fitting suitable for demanding piping applications where standard weight fittings are not appropriate. Licensed plumbers and pipefitters install this type of fitting in threaded iron pipe systems for gas, steam, air, and other compatible services.

This fitting is suited for residential and light commercial piping installations where a 90-degree directional change is required in a threaded iron pipe run. The 3/4-inch size is common in branch lines and distribution piping. The black finish indicates an uncoated malleable iron surface, typical for gas and steam service rather than water service where a galvanized finish is more common.

Key Features

• Extra heavy (XH) wall construction for higher-pressure and higher-demand applications
• 90-degree street configuration with one male and one female threaded end
• 3/4-inch nominal pipe size
• Black finish malleable iron construction
• Threaded connection for use in standard threaded iron pipe systems

Compatibility

Designed as an OEM-style replacement or standard component for 3/4-inch threaded malleable iron pipe systems requiring a 90-degree street elbow in extra heavy classification.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local mechanical and plumbing codes. Shut off and depressurize the pipe system before removing or installing any threaded fitting. Apply an appropriate thread sealant or PTFE tape to male threads before assembly. Do not over-torque the fitting, as malleable iron threads can be damaged by excessive force.

Technical Specifications

• Material: Extra Heavy Malleable Iron
• Finish: Black
• Pipe Size: 3/4 inch
• Configuration: 90 Degree Street Elbow
• Weight: 0.59 pounds
• UPC: 777701203756

Standard Information

• Brand: BMI USA
• Manufacturer Part Number: 20375
