Bmi 46356 1 ftg x press-fit 90 elbow carbon gas

Product Description

The BMI 46356 Carbon Press 90 Degree Street Elbow is a 1 inch press-fit carbon gas fitting designed for secure pipe connections. It is compatible with Sch. 40 Black Iron or Galvanized fittings and pipes meeting ASTM A53, A106, A135, A795 standards. This 90 degree elbow operates effectively within a maximum working pressure of 125 psi and a temperature range of -40°F to 180°F, suitable for various industrial and plumbing applications.

• Equipped with a HNBR sealing element and stainless-steel ring designed with two rows of teeth that grip the pipe and lock the fitting firmly in place
• Protected with a Zinc-Nickel coating and are 100% factory tested before being individually bagged
• Quick installation process using electro-hydraulic press tools, reducing delays and labor costs

Product Highlights

Features HNBR sealing, Zinc-Nickel coating, and quick installation with press tools for reliable pipe connections.

Product Information

Standard Information

• Brand: BMI
• Manufacturer Part Number: 46356

Technical Specifications

• Press Size: 1 inch
• Maximum Working Pressure: 125 psi
• Working Temperature Range: -40°F to 180°F
• Compatible Pipe Standards: ASTM A53, A106, A135, A795
• Compatible Fittings: Sch. 40 Black Iron or Galvanized
