Bmi 46005 carbon press coupling 3/4 inch

Product Description

The BMI 46005 Carbon Press Coupling is a 3/4 inch fitting designed for quick and secure pipe connections. It features an HNBR sealing element and a stainless-steel ring for a firm grip, protected by a Zinc-Nickel coating. This coupling is 100% factory tested and compatible with most commercially available electro-hydraulic press tools, allowing for easy identification of unpressed connections during pressure testing. It supports a maximum working pressure of 125 psi and a working temperature range of -40°F to 180°F.

• Easily recognizable with distinct yellow markings.
• Equipped with an HNBR sealing element and a stainless-steel ring with two rows of teeth for secure pipe grip.
• Protected with a Zinc-Nickel coating and 100% factory tested.

Product Highlights

Quick installation, secure pipe grip, and easy identification of unpressed connections.

Product Information

Standard Information

• Brand: BMI
• Manufacturer Part Number: 46005

Technical Specifications

• Press Size: 3/4 inch
• Working Pressure: 125 psi max
• Working Temperature: -40°F to 180°F
• Pipe Compatibility: Sch. 40 Black Iron or Galvanized fittings only. Pipe must comply with ASTM A53, A106, A135, A795 standards
