BLUE RIBBON CORP BR201L-254E 100 PSI Lower Mount Lead Free Liquid Filled Pressure Gauge

Product Description

The BLUE RIBBON CORP BR201L-254E is a lead-free liquid filled pressure gauge designed for accuracy and safety. Engineered with brass and bronze materials, this gauge is ideal for use in drinking water systems, ensuring lead contamination is minimized. It features a bottom connection for easy installation and is filled with glycerine to dampen vibrations, enhancing measurement consistency.

• Lead-free brass internals and connection
• Lead-free phosphor bronze bourdon tube
• Glycerine fill standard

Product Highlights

This pressure gauge offers a dual scale display in psi and bar, providing versatility for various measurement needs.

Product Information

Standard Information

• Brand: BLUE RIBBON CORP
• Model Number: BR201L-254E

Technical Specifications

• Weight: 1 lb.
• Port Size: 1/4 inch
• Product Type: Pressure Gauge
• Dial Diameter: 2-1/2 inches
• Mounting Type: Lower
• Catalog Number: BR201L-254E
• Housing Material: Stainless Steel
• Maximum Accuracy: 1.6%
• Specifications Met: IP65
• Connection Location: Lower
• Maximum Pressure Rating: 100 PSI
• Minimum Pressure Rating: 0 PSI
• Maximum Ambient Temperature: +15 degrees F
• Minimum Ambient Temperature: 0 degrees F
