Blue Ribbon BR101D-404E 0 to 100 psi 4 inch Dial 1/4 inch MNPT Lower Mount Utility Dry Non-Fillable Pressure Gauge

Product Description

The Blue Ribbon BR101D-404E is a utility pressure gauge designed for measuring pressures from 0 to 100 psi. This gauge features a four-inch dial with a lower mount connection of one-quarter inch MNPT. It is suitable for various applications, including air, water, oil, and gas that are not corrosive to brass. Its steel case and brass socket ensure durability. The gauge is dry and non-fillable, providing reliable readings in different environments.

• Range: 0 to 100 psi
• Connection: 1/4 inch MNPT
• Temperature rating: -50 to 160 degrees Fahrenheit

Product Highlights

This gauge is ideal for commercial applications due to its affordability and reliability. It meets necessary pressure measurement needs across various fields.

Product Information

Standard Information

• Brand: Blue Ribbon
• MPN: BR101D-404E

Technical Specifications

• Dial Diameter: 4 inches
• Type: Utility, Dry, Non-Fillable
• Accuracy: 3-2-3%
• Mounting: Lower
• Material: Steel case, brass socket and movement, phosphor bronze Bourdon tube
• Pressure Range: 0 to 100 psi
• Temperature Rating: -50 to 160 degrees Fahrenheit
