Blue Ribbon BR101D-404C 0 to 30 psi 4 inch Dial 1/4 inch MNPT Lower Mount Utility Dry Non-Fillable Pressure Gauge

Product Description

The Blue Ribbon BR101D-404C is a utility pressure gauge designed to measure pressure accurately across various applications. This gauge has a maximum pressure range of zero to thirty psi and features a standard four-inch dial for clear readability. It employs a one-quarter inch MNPT lower mount for easy installation.

• Utility gauge suitable for air, water, oil, and gas
• Durable construction using brass and steel materials
• High accuracy rating at three percent

Product Highlights

Ideal for commercial use, this gauge is resistant to corrosion and is suitable for various media.

Product Information

Standard Information

• Brand: Blue Ribbon
• Part Number: T1273

Technical Specifications

• Connection Size: 1/4 in MNPT
• Dial Diameter: 4 in
• Material: Steel Case, Brass Socket and Movement, Phosphor Bronze Bourdon Tube
• Pressure Range: 0 to 30 psi
• Accuracy: 3-2-3%
• Temperature Rating: -50 to 160 Deg F
• Mounting: Lower
