Blackburn ICS72-1 SPLICE ENTR SVCE ACSR/SOL/STRD 4 TO 1AWG

Product Description

The Blackburn ICS72-1 is an insulated service entrance splice designed for 4 to 1 AWG ACSR, solid, and stranded conductors. This product is suitable for use in connecting overhead distribution power lines with reliable performance.

• Constructed from aluminum for high conductivity
• Complies with ANSI C119.4 for aluminum connections
• Prefilled with oxide-inhibitor to prevent oxidation

Product Highlights

This splice features solid center barriers and large chamfers for easy cable insertion. It is designed to operate effectively under various environmental conditions.

Product Information

Standard Information

• Brand: Blackburn
• Manufacturer: ABB - Installation Products

Technical Specifications

• Type: Insulated
• Color: Orange/Red
• Length: 2-25/32 inches
• Series: ICS
• Die Code: 5/8
• Conductor Size: 4 to 1 AWG
• Connector Type: Crimp/Compression
• Specifications: 2-Conductor, 0.268 to 0.328 inches Diameter End A, 0.213 to 0.258 inches Diameter End B
