Blackburn ICS67-1 4 TO 6 INS SPLI

Product Description

The Blackburn ICS67-1 is a compression splice designed for service entrance applications. This aluminum splice accommodates wire ranges effectively. It is suitable for various conductor types including ACSR, stranded, and solid wires. The design supports easy installation while ensuring reliable electrical connections.

• Compatible with End A: 4 ASCR, 3-4 Stranded, and 2 Solid wires
• Compatible with End B: 6 ASCR, 6 Stranded, and 4 Solid wires
• Die size measures five eighths inches for efficient performance

Product Highlights

This compression splice is built from aluminum which offers high conductivity and durability.

Product Information

Standard Information

• Brand: Blackburn
• Manufacturer: Blackburn

Technical Specifications

• Size: 2-25/32 inch
• Type: Compression Splice Service Entrance
• Material: Aluminum
• Conductor Range: End A: NO.4 ACSR; NO.3 to NO.4 STR; NO.2 SOL; End B: NO.6 ACSR; NO.6 STR; NO.4 SOL
• Number Of Conductors: 2
• Application: For Standard Conductor Splice
• Standard: RUS Accepted, complies with ANSI C119.4 when properly installed on Aluminum-to-Aluminum connections
• Environmental Conditions: All Seasons / Conditions
