Blackburn CSR-250 CU MECH LUG Power 1 EACH Replacement MPN

Product Description

The Blackburn CSR-250 is a multi-tap encapsulated splice designed for reliable electrical connections. This model is suitable for both copper and aluminum cables and features a one-way configuration with two outlets. With a wire range of two hundred fifty kcmil to six stranded, it fits a variety of electrical applications.

• Clear PVC insulation for safe installation
• Fits wire ranges from 250 kcmil to 6 awg
• Dimensions: Length four inches, Width one point zero six inches, Height two inches

Product Highlights

The CSR-250 offers a versatile design to support multiple cable configurations.

Product Information

Standard Information

• Manufacturer: Blackburn
• Part Number: CSR-250

Technical Specifications

• Wire Range: 250 kcmil - 6 stranded
• Hex Size: 5/16 inch
• Number of Outlets: 2
• Configuration: One-way
• Insulation: Clear PVC
• Shipping Weight: 0.215 pounds
• Shipping Dimensions: 4 inches (length) x 2 inches (width) x 1.06 inches (height)
