Blackburn ADR11 Connector Mech Al/Strd Copper 1/4in 1 Al

Product Description

The Blackburn ADR11 is a mechanical connector designed for aluminum and stranded copper conductors. This connector is compatible with conductor sizes ranging from fourteen to one-aught AWG. Built with convenience in mind, the ADR11 includes easy installation features that do not require special tools.

• Type ADR-ALCUL dual-rated lug
• Suitable for 14 to 1/0 AWG conductor sizes
• Includes 1/4 inch stud and 1 bolt hole

Product Highlights

This mechanical connector is ideal for electrical installations requiring reliable connections. Its tin-plated finish minimizes contact resistance, enhancing electrical performance.

Product Information

Standard Information

• Brand: Blackburn
• Manufacturer: ABB - Installation Products
• UPC: 783786610044

Technical Specifications

• Type: Type ADR-ALCUL Dual-Rated
• Conductor Type: Aluminum/Stranded Copper
• Conductor Size: 14 to 1/0 AWG
• Stud Size: 1/4 inch
• Dimensions: 1-15/32 inches L x 5/8 inches W x 25/32 inches H
• Voltage Rating: 600 VAC
• Number of Bolt Holes: 1
• Finish: Tin Plated
