Best 711068096 Full Mortise Concealed Hinge 3.5in Steel

Product Description

The BEST 711068096 is a full mortise concealed hinge designed for commercial and residential door applications. Built from steel with a satin chrome finish, this 5-knuckle hinge features a non-removable stainless steel pin for added security. Both the door leaf and frame leaf measure 3.5 inches in height with a leaf thickness of 0.123 inches. Two ball bearings provide smooth, consistent swing operation over extended service life. It meets ANSI A8112 and BHMA standards, making it appropriate for code-compliant door hardware installations. Licensed door hardware installers and commercial contractors are the primary installers of this component.

This hinge is suited for full mortise door installations where the hinge is recessed into both the door edge and the door frame. The satin chrome finish coordinates with US26D hardware finishes common in commercial office, institutional, and light industrial door assemblies. The non-removable pin design adds a layer of tamper resistance appropriate for high-traffic or security-conscious environments. It is sold individually and is packaged as a single unit.

Key Features

• Full mortise mount type for flush, recessed installation in door edge and frame
• Steel hinge body with satin chrome finish, Stanley finish code US26D
• Stainless steel non-removable pin for improved tamper resistance
• 5-knuckle design with 2 ball bearings for smooth, durable swing operation
• Meets ANSI A8112 and BHMA standards
• Class 179FBB designation for straightforward specification matching

Compatibility

Designed as an OEM-style replacement or new-installation hinge for full mortise door applications requiring a 3.5-inch leaf height profile.

Installation Notes

Installation is typically performed by a licensed door hardware technician or commercial carpenter. The door and frame must be properly mortised to the correct depth before hinge seating to ensure flush alignment and prevent binding. Confirm the door is fully supported and stationary before fastening. Follow applicable local building codes and manufacturer fastener specifications when securing the hinge leaves.
