Bessey IBEAM72 I-beam Bar Clamp 7000 lb (72 in) IBEAM72

Product Description

The Bessey IBEAM72 is an I-beam bar clamp (MPN IBEAM72) designed for heavy-duty clamping with a 72 in maximum jaw opening and up to 7000 lb of clamping force. The steel, nickel-plated I-beam rail resists bending over long spans while the cast iron sliding jaw uses five clutch plates for smooth movement and secure holding. Key dimensions include a 2 in throat depth, 1-3/4 in jaw width, 1-3/8 in bar width and 7/16 in bar thickness.

• 72 in maximum jaw opening with up to 7000 lb clamping force
• Steel, nickel-plated I-beam rail; 2 in throat depth
• Cast iron sliding clamp jaw with five clutch plates; 1-3/4 in jaw width, 7/16 in bar thickness

Product Highlights

Heavy-duty I-beam bar clamp, 72 in clamping width, 7000 lb capacity, nickel-plated rail and cast iron sliding jaw

Product Information

Standard Information

• Brand: BESSEY
• Manufacturer Part Number: IBEAM72
• Country of Origin: China

Technical Specifications

• Brand: BESSEY
• Manufacturer Part Number: IBEAM72
• SKU: 013-IBEAM72
• Clamping Force: 7000 lb
• Clamping Width (Max): 72 in
• Throat Depth: 2 in
• Jaw Width: 1-3/4 in
• Bar Width: 1-3/8 in
• Bar Thickness: 7/16 in
• Material: Steel (bar), Cast iron (sliding jaw)
• Finish: Powder coated / Nickel-plated I-beam
• Handle Material: Cast iron
• Sliding Mechanism: Clutch
• Clutch Plates: 5
• Spindle Thread: ACME
• Nominal Rail Size: 1-1/2 x 15/32 in
• Overall Length: 81.0 in
• Dimensions (Height x Width): 6.25 in x 2.0 in
• Weight: 14.2 lb
• Country of Origin: China
• UPC: 7885022035240
• Category: Bar Clamps & Spreaders
• Type: I-beam Bar Clamp
