BELL & GOSSETT HEF-50 Relief Valve

Product Description

The BELL & GOSSETT HEF-50 is a bronze hot water relief valve designed for both fired and unfired hot water pressure vessels. This valve effectively protects systems from overpressure situations. It features an angle pattern design with a one inch inlet and a one inch outlet, both equipped with NPT connections. The HEF-50 is set to operate at 50 PSI, supporting up to 1,710,000 BTU per hour. It is suitable for direct fired water heaters and for storage tanks that use indirect heaters, ensuring compatibility with the BTU output of heat exchangers.

• Valve Application: Hot Water
• Connection Size: 1 inch
• Max Pressure: 150 PSI WOG

Product Highlights

This valve enhances safety and efficiency in hot water systems.

Product Information

Standard Information

• Manufacturer: Bell & Gossett
• Model: 1170-50
• MPN: HEF-50
• UPC: 683328101323

Technical Specifications

• Body Material: Brass
• Piping Configuration: Angle
• Connection Type: NPT
• BTU Capacity: 1,710,000 BTU/Hr
• Weight: 19.8 lbs
