Bell & Gossett 404208 Hoffman Specialty Bear Trap Float and Thermostatic Steam Trap 3/4 in

Product Description

Bell & Gossett 404208 is a Hoffman Specialty Bear Trap Float and Thermostatic Steam Trap designed for effective steam management. It is a part of the H Series and features a nominal size of three-quarters of an inch and NPT end style. This steam trap operates effectively at a pressure rating of 250 psig and can withstand temperatures up to 406 degrees Fahrenheit. The construction material is cast iron, ensuring durability and reliability.

• Float and thermostatic design for efficient steam trapping
• Constructed from cast iron for strength
• Rated for high pressure and temperature applications

Product Highlights

This steam trap is designed to prevent steam leakage and ensures proper operation even in challenging conditions.

Product Information

Standard Information

• Brand: Bell & Gossett
• Manufacturer: Xylem

Technical Specifications

• Dimensions: 5-1/2 inches wide x 5-19/32 inches high
• End Style: NPT
• Length: 6-1/2 inches
• Material: Cast Iron
• Nominal Size: 3/4 inches
• Pressure Rating: 250 psig
• Series: H Series
• Temperature Rating: 406 degrees Fahrenheit
