Bell & Gossett 169218 Motor 2HP 3450RPM 208-230/460V 3Ph ODP M99103

Product Description

The Bell & Gossett 169218 is a robust 2HP motor, capable of operating at 3450 RPM with a three-phase 208-230/460V power supply. It is designed specifically for Bell & Gossett Series 90 pumps and features an open drip-proof (ODP) enclosure which makes it suitable for a variety of industrial environments.

• Engineered for reliability in challenging conditions
• Oil-lubricated with a 3/4 inch seal shaft diameter
• Comes with a modern, built-in thermal overload protector

Product Highlights

This motor is equipped with a two-piece motor bracket for easy service, sleeve bearings for longevity, and replaceable, resilient motor mounts that enhance its durability and operational efficiency.

Product Information

Standard Information

• Brand: Bell & Gossett
• MPN: 169218

Technical Specifications

• Power Output: 2 HP
• Operational Voltage: 208-230/460V
• Phase: 3 Ph
• Speed: 3450 RPM
• Enclosure Type: ODP
• Motor Frame Size: 56CVZ
• Series: 90 B&G
