Bell & Gossett 117471 Circuit Setter Plus 5 in Flanged

Product Description

The Bell & Gossett Circuit Setter Plus, model 117471, is a calibrated balance valve designed for hydronic systems. This valve ensures accurate flow measurement and system balancing. The Circuit Setter Plus allows for pre-set proportional balance in HVAC systems, maintaining optimal efficiency. The integration of an easy-to-read valve port simplifies measurement and adjustment tasks.

• Integrated valve readout port for easy access
• Flanged end style with a nominal size of five inches
• Pressure rating of 175 psig and flow rate of seven thousand two hundred gallons per minute

Product Highlights

This valve is suitable for HVAC professionals looking for reliable flow balancing in hydronic systems.

Product Information

Standard Information

• Brand: Bell & Gossett
• MPN: 117471

Technical Specifications

• Body Material: Cast Iron
• Dimensions: Sixteen inches wide x Seventeen and one-quarter inches high (open)
• End Style: Flanged
• Flow Rate: Seven thousand two hundred gallons per minute
• Nominal Size: Five inches
• Port Type: Integrated Valve Readout
• Pressure Rating: One hundred seventy-five psig
• Series: CB-5F
• Softgoods Material: Nitrile Binder Gasket/EPDM Seal Ring
• Temperature Rating: Two hundred fifty degrees Fahrenheit
• Trim Material: Stainless Steel
• Type: Globe
