Bell & Gossett 104306 Ecocirc XL 55-45 Cast Iron Circulator 1/2 HP 208-230V 1 Ph

Product Description

The Bell & Gossett Ecocirc XL 55-45 Circulator is engineered for high-efficiency, featuring a cast iron body and an electronically commutated motor with ECM/PM technology. Perfect for various HVAC applications, this 1/2 HP, 208-230V single-phase pump operates between 1500 to 4500 RPM.

• Designed to handle temperatures up to 230 degrees Fahrenheit.
• Capable of withstanding a maximum working pressure of 175 psi.
• Equipped with multiple control options including proportional, constant pressure, or constant speed settings.

Product Highlights

The pump offers a flow rate of 45 gallons per minute and a maximum head of 55 feet, ensuring robust performance for large-scale applications.

Product Information

Standard Information

• Brand: Bell & Gossett
• MPN: 104306

Technical Specifications

• Motor Power: 1/2 HP
• Voltage: 208-230V
• Phase: Single
• Material: Cast Iron
• Maximum Temperature: 230 degrees Fahrenheit
• Maximum Pressure: 175 psi
• Flow Rate: 45 GPM
• Connection Size: 3/4inch, 1inch, 1-1/4inch, 1-1/2inch
