Bell & Gossett 104302 Ecocirc XL 36-45 Cast Iron Circulator Flanged 1/6 HP 208-230V

Product Description

The Bell & Gossett Ecocirc XL 36-45 Circulator is designed for high efficiency and robust performance in commercial Hydronic systems. Featuring a cast iron body and a power rating of 1/6 horsepower at 208 to 230 volts, this circulator ensures dependability across a broad spectrum of applications.

• Durable cast iron construction with flanged connection ensures a secure fit in a variety of hydraulic settings.
• Electronically commutated motor for reduced energy consumption and optimal performance.
• Multi-function operational modes including constant pressure, speed, and proportional pressure control facilitated by intelligent electronic controls.

Product Highlights

With its advanced motor design and intelligent electronic controls, the Bell & Gossett Ecocirc XL 36-45 Circulator effectively meets the demanding needs of modern commercial hydronic systems, offering both single and three-phase compatibility. The ECM motor provides efficient operation and user-friendly interface makes setup straightforward and easy to manage even for complex systems.

Product Information

Standard Information

• Pump Type: Circulator
• Flow Rate: 45 gpm
• Operating Temperature Range: Up to 230 degrees Fahrenheit

Technical Specifications

• Maximum Head: 36 feet
• Electrical Requirements: 208 to 230 Volts, 1/6 horsepower
• Pressure Handling: Up to 175 psi
• Control Options: Constant speed, proportional pressure, and constant pressure
• Connection: Flanged
• Dimensions: 7.2 inches L x 9.94 inches W x 6.38 inches H
• Weight: 20.00 pounds
