Belimo ZONE220N-50+ZONE24NC Zone Valve 0.75 inches 2 Way 5 Cv w/ Spg Rtn 24V On/Off

Product Description

The BELIMO ZONE220N-50+ZONE24NC is a zone valve with a 0.75" size, 2-way pattern, and a 5 Cv rating. It features a spring return actuator and operates on 24V with on/off control. Designed for use with chilled or hot water with up to 50% glycol. The valve's trim is made of stainless steel.

• Valve Size: 0.75"
• Cv Rating: 5
• Control Type: On/Off

Product Highlights

This Belimo zone valve is ideal for controlling water flow in HVAC systems, providing reliable on/off operation with its spring return actuator.

Product Information

Standard Information

• Brand: BELIMO
• Manufacturer Part Number: ZONE220N-50+ZONE24NC

Technical Specifications

• Angle of Rotation: 90
• Cv: 5
• End Fitting: Internal thread
• Fluid: Chilled or hot water up to 50% glycol
• Pattern: 2-way
• Pressure Independent: NO
• Trim: Stainless steel
• Valve Size: 0.75" [20]
• Actuator Type: Fail-Safe
• Control Type: On/Off
• Degree of Protection: IP20 NEMA 1
• Electrical Connection: cable
• Manual Override: Hand lever
• Power Consumption (Running): 6.5 W
• Running Time (Fail-safe): <5 s
• Input Voltage: AC 24 V
• Valve Pattern: 2-Way
• Connection Type: NPT
• CV Rating: 5
• Body Pressure Rating: 300 psi
• Power Consumption For Wire Sizing: 7 VA
• Protection category: IP20
• Enclosure Type: UL Enclosure Type 1
