Belimo Z2075QPT-G+CQX24-3 | ZoneTight (PIQCV), 3/4, 2-way, 9 | Configurable Valve Actuator, Non fail-safe, AC/DC 24 V, On/Off, Floating point

Product Description

The Belimo Z2075QPT-G+CQX24-3 is a ZoneTight (PIQCV) configurable valve actuator. This model features a three-fourths inch size, two-way design, and can handle up to nine GPM. It operates on AC or DC power at twenty-four volts, enabling on/off and floating point control.

• Configurable for various applications
• Built for chilled or hot water systems
• Available with pressure-independent functionality

Product Highlights

This actuator is designed to meet the needs of HVAC professionals. Its versatility allows it to adapt to many systems, improving performance.

Product Information

Standard Information

• Brand: Belimo
• MPN: Z2075QPT-G+CQX24-3

Technical Specifications

• Valve Size: 0.75 [20]
• Flow: 9 GPM
• Angle of Rotation: 90 degrees
• Fluid Compatibility: Chilled or hot water up to 60% glycol
• End Fitting: Internal thread
• Control Type: Floating/3-point
• Actuator Type: Non fail-safe
• Power Supply: AC/DC 24 V
• Degree of Protection: IP40 NEMA 2
