Product Description
The Belimo NMQB24-1 is a direct coupled actuator designed for effective control of dampers in HVAC systems. It operates with a torque of seventy inch-pounds and is suitable for on/off control applications. This actuator features a brushless DC motor controlled by an application specific integrated circuit. It is electronically protected against overload, enhancing reliability in operational conditions.
- Power consumption: 13 watts running, 1.5 watts holding
- Operating temperature range: -22 degrees Fahrenheit to 122 degrees Fahrenheit
- Electrical connection: 18 gauge plenum rated cable with a half-inch conduit connector
Product Highlights
Ideal for use in HVAC systems where precision and reliability are critical.
Product Information
Standard Information
-
Brand: Belimo
-
MPN: NMQB24-1
Technical Specifications
-
Actuator Type: Non fail-safe
-
Angle of Rotation: 95 degrees
-
Control Type: On/Off
-
Degree of Protection: IP54 NEMA 2 UL Enclosure Type 2
-
Manual Override: External push button
-
Running Time (Motor): 4 seconds to 90 degrees
-
Safety Function: No
-
Torque: 70 in-lb (8 Nm)
-
Voltage AC/DC: AC/DC 24 V
