Belimo LRB24-3 Direct Coupled Actuator 45 in-lb

Product Description

The Belimo LRB24-3 is a direct coupled actuator that delivers forty-five inch-pounds of torque for HVAC applications. This actuator operates at twenty-four volts AC and DC. It is designed for on/off and floating point control. The LRB24-3 features an external push button for manual override.

• Torque: 45 in-lb
• Power Supply: 24 VAC/DC
• Protection: NEMA 2, IP54 rated

Product Highlights

The LRB24-3 provides reliable performance in various HVAC systems. It is ideal for applications that require precise control of dampers and valves.

Product Information

Standard Information

• Brand: Belimo
• MPN: LRB24-3

Technical Specifications

• Actuator Type: Non fail-safe
• Power Consumption: 1.5W running, 0.2W holding
• Operating Conditions: -22°F to 122°F
• Electrical Connection: 3 ft. 18 GA plenum cable with 1/2 in. conduit connector
• Angle of Rotation: 90 degrees
• Degree of Protection: IP54 NEMA2 UL Enclosure Type 2
• Fluid Compatibility: Potable water
• Manual Override: External push button
