Belimo LF24-SR-E US Direct Coupled Actuator 35 in-lb

Product Description

The Belimo LF24-SR-E US is a direct coupled actuator with a torque rating of thirty-five inch-pounds. It operates on twenty-four volts alternating current and is designed for reliable modulating control in HVAC systems. This actuator can handle spring return applications, providing a fail-safe solution for dampers.

• Spring return operation for fail-safe control.
• Modulating with 2 to 10 VDC signal for position feedback.
• Built-in adjustable minimum position for three-position control.

Product Highlights

With a durable design, this actuator provides consistent torque and operates effectively even in stalled conditions. It can be installed directly onto damper shafts with diameters ranging from three-eighths to one-half inch.

Product Information

Standard Information

• Brand: Belimo
• Part Number: LF24-SR-E US

Technical Specifications

• Actuator Type: Spring return
• Torque: 35 in-lb [4 Nm]
• Voltage: AC/DC 24V
• Angle of Rotation: 95 degrees
• Control Type: DC 2 to 10 V
• Degree of Protection: IP54, NEMA 2
• Power Consumption (Running): 2.5 W
• Power Consumption (Holding): 1 W
• Running Time (Fail-safe): Less than 25 seconds
• Electrical Connection: 3 ft. cable with 1/2 inch conduit connector
