Product Description
The Belimo LF120 US Damper Control Actuator offers reliable on-off and fail-safe control for HVAC systems. With 35 in-lb of torque and 120V power, this actuator is both efficient and durable.
- Spring return mechanism
- On/Off control
- Compatible with various shaft sizes
Product Highlights
Ideal for controlling dampers in HVAC systems. Utilizes a spring return mechanism for fail-safe operation. Simple on-off control from an auxiliary contact or manual switch.
Product Information
Standard Information
-
Brand: Belimo
-
MPN: LF120 US
-
Manufacturer: Belimo Air Controls
-
Voltage: 120 Volts
-
Connector Type: Screw
-
National Stock Number: 4520-01-503-4290
Technical Specifications
-
Actuator Type: Spring return
-
Angle of Rotation: 90
-
Control Type: On/Off
-
Cv: 49
-
Degree of Protection: IP54 NEMA 2 UL Enclosure Type 2
-
Electrical Connection: Cable
-
End Fitting: Internal thread
-
Fluid: Potable water
-
Pattern: 2-way
-
Power Consumption (Holding): 3.5 W
-
Power Consumption (Running): 5.5 W
-
Pressure Independent: NO
-
Product Type: Combo
-
Running Time (Fail-safe): <25 s
-
Running Time (Motor): 75 s / 90°
-
Torque: 35 in-lb (4 Nm)
-
Valve Size: 0.75 (20)
-
Voltage AC/DC: AC 120V
