Belimo G680CS+AFX24-MFT-X1 Globe Valve Assembly 2 Way 3 in.

Product Description

Belimo G680CS+AFX24-MFT-X1 is a globe valve assembly designed for HVAC applications. This unit is a two-way valve, suitable for chilled or hot water as well as steam service. It features a direct-coupled actuator with a holding torque of one hundred eighty inch-pounds and can operate at 24 VAC. The valve utilizes Multi-Function Technology to ensure reliable performance in dynamic HVAC systems.

• Flanged design with a Cv of ninety
• Soft seat design for ANSI Class VI leakage rating
• Operating range of fifteen to one hundred psi

Product Highlights

This valve operates effectively in diverse temperatures from negative twenty-two degrees Fahrenheit to one hundred twenty-two degrees Fahrenheit. It is engineered for applications with up to sixty percent glycol and is built from durable materials to ensure longevity and reliability.

Product Information

Standard Information

• Brand: Belimo
• Part Number: G680CS+AFX24-MFT-X1

Technical Specifications

• Valve Size: three inches
• Flow Characteristic: Equal Percentage
• Operating Conditions: -22 F to 122 F (-30 C to 50 C)
• Power Consumption: 7.5 W Running, 3 W Holding
• Electrical Connection: 18 GA Appliance Rated Cable with half inch conduit connector
• Degree of Protection: NEMA 2, IP54
• End Fitting: Flange
• Actuator Type: Spring return
