Belimo G232B-M+LF24 Globe Valve 1.25 2 Way 20 Cv w/ Spring Return 24V On/Off

Product Description

The Belimo G232B-M+LF24 is a globe valve designed for efficient flow control in HVAC applications. This valve features a size of one point two five inches and is suitable for two-way operation. It operates on twenty volts and utilizes a spring return actuator, making it ideal for on/off control in heating and cooling systems.

• Spring return actuator
• Two-way flow pattern
• Compatible with chilled or hot water up to sixty percent glycol

Product Highlights

The G232B-M+LF24 valve is reliable for controlling the flow in various systems. It is designed for easy installation and maintenance. The actuator offers protection rated at IP54, making it suitable for different environmental conditions.

Product Information

Standard Information

• Brand: Belimo
• MPN: G232B-M+LF24

Technical Specifications

• Valve Size: 1.25 [32]
• Cv: 20
• Fluid Compatibility: Chilled or hot water up to 60% glycol steam
• Angle of Rotation: 90 degrees
• ANSI Class: 250
• End Fitting: Internal thread
• Pressure Independent: NO
• Trim Material: Bronze
• Actuator Type: Spring return
• Voltage AC/DC: AC/DC 24V
• Power Consumption (Holding): 2.5 W
• Power Consumption (Running): 5 W
• Electrical Connection: Cable
• Running Time (Motor): 75 seconds / 90 degrees
• Degree of Protection: IP54 NEMA 2
