Product Description
The Belimo G225S-L+LF24-MFT is a globe valve designed for reliable control of chilled or hot water systems. This valve features a spring return actuator and operates at twenty-four volts. It supports a two-way water flow pattern and has a flow coefficient of fourteen. The compact design makes it suitable for various HVAC installations.
- Spring return actuator for dependable operation
- Two-way design with a Cv of fourteen
- Compatible with chilled and hot water applications
Product Highlights
The G225S-L+LF24-MFT is ideal for plumbing applications where precise control of water flow is necessary.
Product Information
Standard Information
-
Brand: Belimo
-
MPN: G225S-L+LF24-MFT
Technical Specifications
-
Valve Size: 1 [25]
-
Cv: 14
-
Fluid: Chilled or hot water up to 60% glycol steam
-
Pattern: 2-way
-
Angle of Rotation: 90
-
Trim: Stainless steel
-
End Fitting: Internal thread
-
ANSI Class: 250
-
Pressure Independent: No
-
Actuator Type: Spring return
-
Voltage AC/DC: AC/DC 24 V
-
Degree of Protection: IP54 NEMA 2
-
Power Consumption (Holding): 1 W
-
Power Consumption (Running): 2.5 W
-
Running Time (Fail-safe): Less than 25 s
-
Running Time (Motor): 150 s / 90 B0
-
Electrical Connection: Cable
-
Controllable Flow Range: Stem up - open A b AB
