Belimo G225S-L+LF120-S Globe Valve Power 120V 1 Replacement MPN

Product Description

The Belimo G225S-L+LF120-S is a globe valve designed for regulating fluid flow. This two-way valve features a Cv rating of 14, enabling effective control of chilled or hot water applications, including systems with up to sixty percent glycol. The valve operates with a spring return actuator, powered by 120 volts, and is suitable for on/off control in various HVAC systems.

• Works with chilled or hot water and up to sixty percent glycol
• Spring return actuator with one SPDT auxiliary switch
• Durable stainless steel trim for long-lasting use

Product Highlights

The G225S-L+LF120-S valve provides reliable performance in HVAC systems, allowing for precise control of fluid flow.

Product Information

Standard Information

• Brand: Belimo
• MPN: G225S-L+LF120-S

Technical Specifications

• Valve Size: 1 inch
• Pattern: 2-way
• Angle of Rotation: 90 degrees
• ANSI Class: 250
• Controllable Flow Range: Stem up - open A b AB
• End Fitting: Internal thread
• Fluid Type: Chilled or hot water up to 60% glycol steam
• Pressure Independent: NO
• Trim Material: Stainless steel
• Actuator Type: Spring return
• Auxiliary Switches: 1 x SPDT
• Degree of Protection: IP54 NEMA2
• Electrical Connection: cable
• Power Consumption (Holding): 3.5 W
• Power Consumption (Running): 5.5 W
• Running Time (Fail-safe): Less than 25 seconds
• Running Time (Motor): 75 seconds at 90 degrees
• Voltage AC/DC: AC 120 V
