Product Description
The Belimo G225B-L+LF120-S is a globe valve designed for efficient control of chilled or hot water systems. This valve operates with a spring return actuator, making it suitable for on/off applications at a voltage of one hundred twenty volts.
- Two-way valve configuration
- Cv rating of fourteen
- Compatible with various fluid types including water and steam
Product Highlights
The G225B-L+LF120-S offers reliable performance in HVAC systems, facilitating smooth flow regulation.
Product Information
Standard Information
-
Brand: Belimo
-
MPN: G225B-L+LF120-S
Technical Specifications
-
Angle of Rotation: 90 degrees
-
ANSI Class: 250
-
Controllable Flow Range: Stem up - open A b AB
-
Cv: 14
-
End Fitting: Internal thread
-
Fluid Compatibility: Chilled or hot water up to sixty percent glycol and steam
-
Pattern: 2-way
-
Pressure Independent: No
-
Trim Material: Bronze
-
Valve Size: 1 inch (25 mm)
-
Actuator Type: Spring return
-
Auxiliary Switches: 1 x SPDT
-
Degree of Protection: IP54 NEMA 2
-
Electrical Connection: Cable
-
Power Consumption (Holding): 3.5 W
-
Power Consumption (Running): 5.5 W
-
Running Time (Fail-safe): Less than 25 seconds
-
Running Time (Motor): 75 seconds / 90 degrees
-
Voltage: AC 120 V
