Belimo G225B-K+LF24-S | Globe Valve | 1 | 2 Way | 10 Cv | w/ Spring Return | 24V | On/Off | SW

Product Description

The Belimo G225B-K+LF24-S is a two-way globe valve designed for reliable operation in HVAC systems. With a Cv rating of 10, this valve is suitable for both chilled and hot water applications, handling fluid mixes of up to sixty percent glycol. It operates on 24V power with spring return functionality, ensuring efficient on/off control in various applications.

• Two-way operation for controlling fluid flow.
• Spring return actuator for reliable performance.
• Compatible with various fluids, including steam.

Product Highlights

This globe valve is ideal for HVAC professionals looking for a durable and efficient solution for temperature and flow control in heating or cooling systems.

Product Information

Standard Information

• Category: Belimo
• MPN: G225B-K+LF24-S

Technical Specifications

• Angle of Rotation: 90 degrees
• ANSI Class: 250
• Controllable Flow Range: Stem up - open A b AB
• Cv: 10
• End Fitting: Internal thread
• Fluid: Chilled or hot water up to 60% glycol steam
• Pattern: 2-way
• Pressure Independent: NO
• Trim: Bronze
• Valve Size: 1 inch (25 mm)
• Actuator Type: Spring return
• Auxiliary Switches: 1 x SPDT
• Degree of Protection: IP54 NEMA 2
• Electrical Connection: Cable
• Power Consumption (Holding): 2.5 W
• Power Consumption (Running): 5 W
• Running Time (Fail-safe): Less than 25 seconds
• Running Time (Motor): 75 seconds at 90 degrees
• Voltage AC/DC: AC/DC 24 V
