Belimo G225B-K+LF120-S Globe Valve 1 2 Way 10 Cv w/ Spring Return 120V On/Off SW

Product Description

The Belimo G225B-K+LF120-S is a globe valve designed for various fluid control applications. This model features a two-way design, allowing for efficient regulation of flow in heating and cooling systems. With a Cv rating of ten, this valve ensures optimal flow control. The spring return actuator operates on a 120V power supply for reliable on/off functionality.

• Two-way flow regulation
• Spring return actuator
• Compatible with chilled or hot water systems

Product Highlights

This valve is suitable for both chilled and hot water applications, capable of handling up to sixty percent glycol steam. With a robust construction and reliable performance, it is ideal for HVAC systems.

Product Information

Standard Information

• Brand: Belimo
• MPN: G225B-K+LF120-S

Technical Specifications

• Angle of Rotation: 90
• ANSI Class: 250
• Controllable Flow Range: Stem up - open A b AB
• Cv: 10
• End Fitting: Internal thread
• Fluid: Chilled or hot water up to 60% glycol steam
• Pattern: 2-way
• Pressure Independent: NO
• Trim: Bronze
• Valve Size: 1 [25]
• Actuator Type: Spring return
• Auxiliary Switches: 1 x SPDT
• Degree of Protection: IP54 NEMA 2
• Electrical Connection: cable
• Power Consumption (Holding): 3.5 W
• Power Consumption (Running): 5.5 W
• Running Time (Fail-safe): < 25 s
• Running Time (Motor): 75 s / 90°
• Voltage AC/DC: AC 120 V
