Belimo G225B-K+LF120 Globe Valve 1 2 Way 10 Cv with Spring Return 120V On/Off

Product Description

The Belimo G225B-K+LF120 is a reliable globe valve designed for effective control in HVAC systems. It features a spring return actuator that operates at 120 volts. This valve is a two-way type with a ten Cv rating. It is suitable for chilled or hot water applications and can handle fluids with up to 60% glycol. This model is ideal for maintaining efficient flow and temperature control in various heating and cooling systems.

• Spring return actuator for reliable operation
• Two-way design with a Cv rating of 10
• Suitable for chilled or hot water applications

Product Highlights

This globe valve integrates easily into HVAC systems. It is designed for durability and efficient performance in residential and commercial settings.

Product Information

Standard Information

• Brand: Belimo
• MPN: G225B-K+LF120

Technical Specifications

• Valve Size: 1 inch
• Angle of Rotation: 90 degrees
• ANSI Class: 250
• Cv: 10
• Trim: Bronze
• Fluid Types: Chilled or hot water up to 60% glycol
• Pressure Independent: No
• Voltage: AC 120V
• Power Consumption (Running): 5.5 W
• Degree of Protection: IP54 NEMA2
