Belimo G220B-K+LF24-SR-S Globe Valve 0.75 2 Way 7.5 Cv w/ Spring Return 24V

Product Description

The Belimo G220B-K+LF24-SR-S is a globe valve designed for fail-safe, modulating control of dampers in HVAC systems. This valve is essential for maintaining effective airflow and temperature regulation in various applications. The actuator mounts directly to a damper shaft ranging from three-eighths to one-half inches in diameter. A universal clamp helps secure the installation. For larger shafts, a K6-1 accessory is needed.

• Modulating control with spring return actuator
• Compatible with chilled or hot water up to sixty percent glycol steam
• Works with 2-10 V control input or 4-20 mA with resistor

Product Highlights

This globe valve is suitable for HVAC professionals who require reliable operation in their systems.

Product Information

Standard Information

• Brand: Belimo
• MPN: G220B-K+LF24-SR-S

Technical Specifications

• Valve Size: 0.75 inches
• Angle of Rotation: 90 degrees
• Cv: 7.5
• Pattern: 2-way
• Fluid: Chilled or hot water up to 60% glycol steam
• End Fitting: Internal thread
• Actuator Type: Spring return
• Power Consumption (Holding): 1 W
• Power Consumption (Running): 2.5 W
• Voltage AC/DC: 24 V
• Degree of Protection: IP54 NEMA2
• Running Time (Fail-safe): Less than 25 seconds
• Running Time (Motor): 150 seconds / 90 degrees
