Belimo G220B-J+LF120 Globe Valve 0.75 2 Way 5.5 Cv w/ Spring Return 120V

Product Description

The Belimo G220B-J+LF120 is a globe valve designed for efficient flow control in various applications. This model features a size of 0.75 inches and operates as a 2-way valve with a Cv rating of 5.5. It is equipped with a spring return actuator for reliable operation at a voltage of 120V.

• Suitable for chilled or hot water and steam applications
• Effective flow regulation with a controllable flow range
• IP54 rated for protection against dust and moisture

Product Highlights

This valve is ideal for HVAC systems and other fluid control applications. The internal thread end fitting ensures a secure connection.

Product Information

Standard Information

• Brand: Belimo
• Part Number: G220B-J+LF120

Technical Specifications

• Angle of Rotation: 90
• ANSI Class: 250
• Controllable Flow Range: Stem up - open A b AB
• Cv: 5.5
• End Fitting: Internal thread
• Fluid: Chilled or hot water up to 60% glycol steam
• Pattern: 2-way
• Pressure Independent: NO
• Trim: Bronze
• Valve Size: 0.75 [20]
• Actuator Type: Spring return
• Degree of Protection: IP54 NEMA 2
• Electrical Connection: cable
• Power Consumption (Holding): 3.5 W
• Power Consumption (Running): 5.5 W
• Running Time (Fail-safe): <25 s
• Running Time (Motor): 75 s / 90B0
• Voltage AC/DC: AC 120 V
