Belimo FSNF24-S US Fire And Smoke Actuator 70 in-lb

Product Description

The Belimo FSNF24-S US Fire And Smoke Actuator is designed for effective performance in HVAC systems. This actuator operates on 24 VAC/DC and has a torque rating of seventy inch-pounds. It provides spring return functionality, ensuring damper closure during a power failure.

• Spring return system for reliable operation.
• Rated for temperatures up to three hundred fifty degrees Fahrenheit for thirty minutes.
• Fifteen-second cycle time for quick actuation.

Product Highlights

Use this actuator in ventilation and air conditioning systems for fire and smoke control. It meets UL555S standards, making it suitable for safety systems.

Product Information

Standard Information

• Brand: Belimo
• Part Number: FSNF24-S US

Technical Specifications

• Auxiliary Switch: 2 x SPDT
• Power Consumption: 24 VA Running, 6.5 VA Holding
• Operating Conditions: 32 F to 122 F (0 C to 50 C)
• Electrical Connection: 3 ft. 18 GA, 2 Color Coded Leads
• Degree of Protection: IP40 NEMA Type 1
• Direction of Rotation (Fail-Safe): Reversible with cw/ccw mounting
• Running Time (Fail-safe): 15 seconds
• Voltage AC/DC: AC/DC 24 V
