Belimo CQKB24-SR-LR Direct Coupled Actuator 12 in-lb

Product Description

The Belimo CQKB24-SR-LR is a direct coupled actuator designed for HVAC applications. It operates with 24 VAC electrical power and is suitable for modulating control. This actuator provides electronic fail-safe functions. The actuator is straightforward to install as it mounts directly to the valve without tools or extra linkage.

• Electrical Fail-Safe feature ensures reliable operation.
• Suitable for control signals of 2 to 10 VDC or 4 to 20 mA.
• Compact design allows for easier installation in tight spaces.

Product Highlights

This actuator is ideal for professionals in HVAC looking for a reliable and efficient valve control solution.

Product Information

Standard Information

• Brand: Belimo
• Part Number: CQKB24-SR-LR

Technical Specifications

• Housing: NEMA 2, IP40
• Power Consumption: 2.5 W Running, 0.5 W Holding
• Operating Conditions: 35 F to 104 F (1.7 C to 40 C)
• Electrical Connection: 3 ft. 18 GA Plenum Cable with 1/2 in. Conduit Connector
• Angle of Rotation: 90 degrees
• Control Type: DC 2 to 10 V
• Running Time (Fail-safe): Less than 60 seconds
• Voltage AC/DC: AC/DC 24 V
