Belimo B352+ARX24-SR-T N4 CCV Assembly 3 Way 2 in NPT 83 Cv

Product Description

The Belimo B352+ARX24-SR-T N4 is a characterized control valve assembly designed for HVAC systems. This model features a two-inch NPT size and an eighty-three Cv flow coefficient. It is suitable for use in air handling units and fan coil units.

• Forged brass construction with nickel plating for durability
• Direct coupled actuator with a maximum torque of one hundred eighty in-lb
• Compatible with 24 VAC control signals

Product Highlights

This valve operates efficiently in hydronic systems with variable or constant flow conditions.

Product Information

Standard Information

• Brand: Belimo
• MPN: B352+ARX24-SR-T N4

Technical Specifications

• Housing: IP66/67, NEMA 4X
• Service: Chilled and hot water, up to sixty percent glycol
• Power Consumption: 2.5 W running, 0.4 W holding
• Close-Off Pressure: 200 psi
• Flow Characteristic: A-Port equal percentage, B-Port modified for constant common port flow
• Operating Conditions: -22°F to 122°F (-30°C to 50°C)
• Electrical Connection: Terminal block
• Angle of Rotation: Ninety degrees
