Product Description
The Belimo B351+ARX24-SR-T N4 is a characterized control valve designed for use in HVAC systems. This valve features a forged brass construction with a nickel-plated brass body for durability and resistance to corrosion. It includes a stainless steel ball and stem and operates with a direct coupled actuator.
- Rated for water temperatures up to 250 degrees Fahrenheit.
- Compatible with chilled or hot water systems with up to sixty percent glycol.
- Modulating control with a non-spring return actuator.
Product Highlights
Utilized in air handling units, this valve is suitable for heating or cooling coils in fan coil units and hydronic systems.
Product Information
Standard Information
-
Brand: Belimo
-
MPN: B351+ARX24-SR-T N4
Technical Specifications
-
Valve Size: 2 inches
-
Flow Cv: 68
-
Connection Type: NPT
-
Angle of Rotation: 90 degrees
-
Operating Conditions: -22°F to 122°F
-
Electrical Connection: Terminal Block
-
Power Consumption: 2.5 watts running, 0.4 watts holding
-
Close-Off Pressure: 200 psi
-
Degree of Protection: IP66/67, NEMA 4X
