Belimo B350+ARX24-SR-T N4 | CCV | 2 | 3 Way | 57 Cv | w/ Non-Spg | 24V | 2-10V | NEMA 4H

Product Description

The Belimo B350+ARX24-SR-T N4 is a characterized control valve designed for precise flow control in HVAC systems. It operates with a voltage of twenty-four volts and supports a control type of direct current ranging from two to ten volts. This model is a three-way valve with a nominal flow coefficient of fifty-seven, suitable for chilled or hot water applications up to sixty percent glycol concentration.

• Controls flow in HVAC systems
• Operates at 24V with a 2-10V control signal
• 3-way valve suitable for various fluid types

Product Highlights

This valve is equipped with a stainless steel trim and an internal thread end fitting, ensuring durability and compatibility with standard piping systems.

Product Information

Standard Information

• Brand: Belimo
• MPN: B350+ARX24-SR-T N4

Technical Specifications

• Angle of Rotation: 90 degrees
• Controllable Flow Range: 75B0
• Cv: 57
• End Fitting: Internal thread
• Fluid: Chilled or hot water up to 60% glycol
• Pattern: 3-way
• Pressure Independent: No
• Trim: Stainless steel
• Valve Size: 2 inches (50mm)
• Actuator Type: Non fail-safe
• Control Type: DC 2...10 V
• Degree of Protection: IP66/67 NEMA 4X UL Enclosure Type 4X
• Electrical Connection: Terminals
• Manual Override: Under cover
• Power Consumption (Holding): 0.4 W
• Power Consumption (Running): 2.5 W
• Running Time (Motor): 90 seconds / 90 degrees
• Voltage AC/DC: AC/DC 24 V
