Belimo B349+AFRB24 CCV 2 3 Way 46 Cv w/ Spg Rtn 24V On/Off

Product Description

The Belimo B349+AFRB24 is a high-performance control valve designed for HVAC applications. It features a three-way configuration with a flow coefficient of forty-six Cv. This valve operates on twenty-four volts and utilizes on/off control, making it suitable for various heating and cooling systems.

• Three-way design for versatile flow control.
• Spring return actuator for reliable operation.
• Compatible with both chilled and hot water systems.

Product Highlights

The B349+AFRB24 provides efficient fluid regulation in HVAC systems. Ideal for applications that require precise temperature control, this valve is built for durability and ease of installation.

Product Information

Standard Information

• Brand: Belimo
• MPN: B349+AFRB24

Technical Specifications

• Angle of Rotation: 90 degrees
• Controllable Flow Range: 75 degrees
• Cv: 46
• End Fitting: Internal thread
• Fluid: Chilled or hot water up to 60% glycol
• Pattern: 3-way
• Pressure Independent: No
• Trim: Stainless steel
• Valve Size: 2 inches [50 mm]
• Actuator Type: Spring return
• Control Type: On/Off
• Degree of Protection: IP54 NEMA 2 UL Enclosure Type 2
• Electrical Connection: Cable
• Manual Override: 5 mm hex crank (3/16 Allen) supplied
• Power Consumption (Holding): 2.5 W
• Power Consumption (Running): 5 W
• Running Time (Fail-safe): Less than 20 seconds
• Running Time (Motor): 75 seconds / 90 degrees
• Voltage AC/DC: 24 V AC/DC
