Belimo B330+ARX24-SR-T N4 | CCV | 1.25 | 3 Way | 19 Cv | w/ Non-Spg | 24V | 2-10V | NEMA 4H

Product Description

The Belimo B330+ARX24-SR-T N4 is a characterized control valve designed for precise flow control in HVAC applications. It operates with a voltage of 24V and features a 3-way pattern for effective fluid distribution.

• Valve size is 1.25 inches with a flow capacity of 19 Cv.
• Compatible with chilled and hot water fluids, accommodating up to 60% glycol.
• Non fail-safe actuator type with manual override under cover.

Product Highlights

This valve is ideal for professionals seeking reliable control over water flow in HVAC systems.

Product Information

Standard Information

• Brand: Belimo
• MPN: B330+ARX24-SR-T N4

Technical Specifications

• Angle of Rotation: 90 degrees
• Controllable Flow Range: 75 B0
• Cv: 19
• End Fitting: Internal thread
• Fluid Compatibility: Chilled or hot water up to 60% glycol
• Pattern: 3-way
• Pressure Independent: No
• Trim Material: Stainless steel
• Valve Size: 1.25 inches
• Actuator Type: Non fail-safe
• Control Type: DC 2...10 V
• Degree of Protection: IP66/67 NEMA 4X UL Enclosure Type 4X
• Electrical Connection: Terminals
• Manual Override: Under cover
• Power Consumption (Holding): 0.4 W
• Power Consumption (Running): 2.5 W
• Running Time (Motor): 90 seconds / 90 degrees
• Voltage AC/DC: AC/DC 24 V
