Belimo B329 ARX24-SR-T N4 | CCV | 1.25 | 3 Way | 10 Cv | w/ Non-Spg | 24V | 2-10V | NEMA 4H

Product Description

The Belimo B329 ARX24-SR-T N4 is an efficient 3-way control valve with a valve size of 1.25 inches. This valve is suitable for controlling the flow of chilled or hot water with up to 60 percent glycol. It operates at a power voltage of 24 volts and features an actuator type that is non-fail-safe. The valve is designed for easy integration in HVAC systems and complies with NEMA 4 standards.

• Power Supply: 24V AC/DC
• Control Signal: 2-10V DC
• Pressure Independent: No

Product Highlights

This valve is ideal for HVAC applications, ensuring precise control of water flow in various environments.

Product Information

Standard Information

• Brand: Belimo
• Part Number: B329 ARX24-SR-T N4

Technical Specifications

• Angle of Rotation: 90 degrees
• Controllable Flow Range: 75 B0
• Cv: 10
• End Fitting: Internal thread
• Fluid: Chilled or hot water up to 60% glycol
• Pattern: 3-way
• Trim: Stainless steel
• Voltage AC/DC: AC/DC 24V
• Manual Override: Under cover
• Running Time (Motor): 90 seconds / 90 degrees
