Belimo B325+LRB24-3 CCV 1 3 Way 30 Cv w/ Non-Spg 24V Floating

Product Description

The Belimo B325+LRB24-3 is a characterized control valve designed for efficient flow control. It features a three-way design, making it ideal for mixing or diverting chilled or hot water systems. The valve works with a voltage of twenty-four volts and operates with a floating control type, offering reliable performance in HVAC applications.

• Three-way mixing or diverting capabilities
• Voltage: 24V, Non fail-safe actuator type
• Maximum Cv rating of 30

Product Highlights

The valve is essential for HVAC systems that manage fluid temperature and flow rates effectively.

Product Information

Standard Information

• Manufacturer: Belimo
• MPN: B325+LRB24-3

Technical Specifications

• Angle of Rotation: 90 degrees
• Controllable Flow Range: 75 degrees
• Cv Rating: 30
• End Fitting: Internal thread
• Fluid: Chilled or hot water up to 60% glycol
• Pattern: 3-way
• Pressure Independent: No
• Trim Material: Stainless steel
• Valve Size: 1 inch (25 mm)
• Actuator Type: Non fail-safe
• Control Type: Floating/3-point
• Degree of Protection: IP54 NEMA2 UL Enclosure Type2
• Electrical Connection: Cable
• Manual Override: External push button
• Power Consumption (Holding): 0.2 W
• Power Consumption (Running): 1.5 W
• Running Time (Motor): 90 seconds / 90 degrees
• Voltage: AC/DC 24 V
