Belimo B323 CCV 3 Way 1 in NPT 10 Cv

Product Description

Belimo B323 is a characterized control valve designed for hydronic systems. This 3-way valve operates with a nominal pipe thread size of one inch and offers a flow control capacity of ten Cv. It features a robust forged brass body with a nickel-plated finish and a stainless steel ball and stem. The valve is effective for both heating and cooling applications.

• Compatible in variable or constant flow systems
• Suitable for air handling units and fan coil units
• Rated for water temperatures up to two hundred fifty degrees Fahrenheit

Product Highlights

This control valve provides stable regulation of heating and cooling, enhancing system efficiency and energy consumption management.

Product Information

Standard Information

• Brand: Belimo
• MPN: B323

Technical Specifications

• Valve Type: 3-way
• Trim Material: Stainless steel
• Fluid Types: Chilled or hot water with up to sixty percent glycol
• Flow Characteristic: Equal percentage
• Operating Conditions: Zero to two hundred fifty degrees Fahrenheit (-eighteen to one hundred twenty degrees Celsius)
• Close-Off Pressure: Two hundred psi
• End Fitting: Internal thread
• Body Pressure Rating: Six hundred psi
• Weight: One point twenty-seven pounds
• Dimensions: Three point zero five inches length, two point six inches width, two point five inches height
