Product Description
The Belimo B321+LRB24-3-S is a characterized control valve designed for precise flow control in HVAC systems. Engineally designed for ease of use and longevity, this valve is optimal for regulating the flow in both hot and chilled water systems.
- Specializes in floating point control with a 24V actuator.
- Features a three-way flow pattern enhancing versatility in installation.
- Constructed with a stainless steel trim to ensure durability and corrosion resistance.
Product Highlights
This valve offers a compact 0.75-inch size and includes a non-spring return mechanism, which simplifies maintenance and reduces mechanical wear. The inclusion of an external push button for manual override provides added convenience for adjustments.
Product Information
Standard Information
-
Brand: Belimo
-
MPN: B321+LRB24-3-S
Technical Specifications
-
Type: CCV, 3-Way
-
Size: 0.75 inches
-
Flow Coefficient (Cv): 24
-
Actuation: 24V AC/DC, floating
-
Connection Type: Internal thread
-
Material: Stainless steel trim
-
Protection: IP54, NEMA 2
-
Power Consumption: 1.5 W (Running), 0.2 W (Holding)
