Belimo B309B+LRB24-SR Characterized Control Valve 0.5 Inch 3-Way 0.8 Cv with Non-Spring Return 24V DC

Product Description

The Belimo B309B+LRB24-SR characterized control valve is designed for precision flow control in HVAC and hydronic systems. Featuring a 0.5 inch 3-way design with a 0.8 Cv, it is equipped with a non-spring return actuator and operates on a 24V DC power supply. Excellent for air handling units, fan coil units, and other applications requiring reliable flow control.

• Optimized for both variable and constant flow systems.
• Constructed from chrome-plated brass for durability.
• Incorporates manual override and IP54 protection.

Product Highlights

This valve facilitates precise temperature and flow control in various HVAC setups, ensuring efficient system operation.

Technical Specifications

• Valve Type: CCV 0.5 inch, 3-way
• Flow Coefficient (Cv): 0.8
• Actuator: Valve Act, non-spring return, DC 2...10V
• Material: Chrome plated brass
• Operating Voltage: AC/DC 24V
• Protection Class: IP54 NEMA 2
• Angle of Rotation: 90 degrees
• Connection Type: Internal thread
• Manual Override: External push button
