Belimo B278+ARX24-SR-T N4 CCV Assembly 2 Way 3 in NPT 130 Cv

Product Description

The Belimo B278+ARX24-SR-T N4 is a 2-way control valve designed for water flow management. It features a nickel-plated brass body with stainless steel components for durability and reliability. This valve operates with a direct coupled actuator and is powered by 24 VAC/DC. It modulates based on a control signal ranging from 2 to 10 VDC or 4 to 20 mA.

• Nickel plated brass body
• Stainless steel ball and stem
• Non fail-safe actuator

Product Highlights

This valve is suitable for chilled or hot water applications and effectively handles fluid up to 60% glycol mixtures. It provides precise flow control with a Cv of 130, making it ideal for various HVAC systems.

Product Information

Standard Information

• Brand: Belimo
• Part Number: B278+ARX24-SR-T N4

Technical Specifications

• Valve Size: 3 inches
• Flow Control Type: 2-way
• Minimum Order Quantity: 1
• Pressure Independent: No
• Degree of Protection: IP66/67 NEMA 4X
• Electrical Connection: Terminals
• Power Consumption (Holding): 0.4 W
• Power Consumption (Running): 2.5 W
