Belimo B277+ARX24-SR-T N4 CCV Assembly 2 Way, 3 in NPT, 70 Cv

Product Description

The Belimo B277+ARX24-SR-T N4 is a characterized control valve designed for wiring in heating and cooling systems.

• Direct coupled actuator with 180 in-lb torque
• Operates at 24 VAC with modulating control
• Suitable for a variety of fluid types including chilled and hot water

Product Highlights

This control valve is efficient and strong, made for air handling units and fan coil units. It features a forged brass body with a nickel-plated finish, ensuring durability. The valve is designed for varied applications in hydronic systems with variable flow.

Product Information

Standard Information

• Brand: Belimo
• Part Number: B277+ARX24-SR-T N4
• Minimum Order Quantity: 1

Technical Specifications

• Close-Off Pressure: 100 psi
• Flow Characteristic: Equal Percentage
• Electrical Connection: Terminal Blocks
• Operating Conditions: -22 F to 122 F
• Power Consumption: 2.5 W Running, 0.4 W Holding
• Valve Size: 3 inches
• Angle of Rotation: 90 degrees
• NEMA Rating: NEMA 4X
