Belimo B265+ARX24-SR-T N4 CCV Assembly 2 Way 2.5 NPT

Product Description

The Belimo B265+ARX24-SR-T N4 is a 2-way control valve assembly designed for HVAC applications. It features a nickel-plated brass body, stainless steel ball and stem, and a direct coupled actuator. This valve offers modulating control with a 210 Cv and operates on 24 VAC/DC for effective performance.

• Characterized control valve for efficient flow regulation
• Compatible with both chilled and hot water systems
• Perfect for 2-10 VDC or 4-20 mA control signals

Product Highlights

The B265+ARX24-SR-T N4 ensures reliable control and is designed for robust performance in various applications.

Product Information

Standard Information

• Brand: Belimo
• Part Number: B265+ARX24-SR-T N4

Technical Specifications

• Valve Size: 2.5 inches
• Cv: 210
• Fluid Type: Chilled or hot water up to 60% glycol
• Control Type: DC 2...10 V
• Degree of Protection: IP66/67 NEMA 4X
• Voltage: AC/DC 24 V
• Running Time (Motor): 90 seconds for 90 degrees
• Power Consumption (Running): 2.5 W
