Belimo B263+AFRX24-MFT CCV Assembly 2 Way 2 1/2 in NPT

Product Description

The Belimo B263+AFRX24-MFT is a characterized control valve designed for use in heating and cooling systems. This two-way valve measures two and a half inches in NPT. It features a direct coupled actuator with a torque rating of one hundred eighty inch-pounds and operates on twenty-four volts AC. The valve is suitable for hydronic systems with variable flow, offering reliable service in dynamic environments.

• Designed for air handling, heating, and cooling coils.
• Offers self-cleaning properties with zero leakage.
• Compatible with water temperatures up to two hundred fifty degrees Fahrenheit.

Product Highlights

The B263+AFRX24-MFT valve incorporates multi-function technology, enabling precise control in varied applications such as chilled and hot water systems.

Product Information

Standard Information

• Brand: Belimo
• Part Number: B263+AFRX24-MFT

Technical Specifications

• Housing: NEMA 2, IP54, UL Enclosure Type 2
• Service: Chilled, Hot Water, Up To 60% Glycol
• Power Consumption: 7.5 W Running, 3 W Holding
• Close-Off Pressure: 100 psi
• Flow Characteristic: Equal Percentage
• Operating Conditions: -22 F To 122 F (-30 C To 50 C)
• Electrical Connection: 3 ft. 18 GA Appliance Cable With 1/2 in. Conduit Connector
• Trim: Stainless steel
• Valve Size: 2.5 inches
